Name: Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled
Brand: TISCO,ANSTEEL,BASTEEL
SKU: A36 Q235 Q345
Price: 500.00 USD
Availability: InStock
Rating: 4.6 (176 reviews)

Home > products > Carbon Steel Plate Sheet >

Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled

JIS Carbon Steel Structural Plate

Mild Carbon Steel Structural Plate

Cold Rolled Carbon Steel Plate ASTM A36

Place of Origin:

China

Brand Name:

TISCO,ANSTEEL,BASTEEL

Certification:

SGS, API, GS, JIS IOS9001 etc.

Model Number:

A36 Q235 Q345

Request A Quote

Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled

Product Details

Material:

A36 Q235 Q345

Standard:

AiSi, ASTM, DIN, JIS

Technique:

Hot Rolled / Cold Rolled

Processing Service:

Bending, Welding, Cutting

Length:

Customized

Width:

1250mm -1500mm Or Customed

Color:

Natutral Color

Surface Treatment:

Coated, Galvanized, Coated

Payment & Shipping Terms

Minimum Order Quantity

5 tons

Price

$500.00 - $700.00/ ton

Packaging Details

Packaged with water proof paper, inner protective steel ring, protective wood block, metal band strapping.

Delivery Time

5-8 work days

Payment Terms

L/C, T/T, D/P

RELATED PRODUCTS

+86-181-140-566-58

sale@carbon-steels.com

86-181-1405-6658

Contact Now

Product Description

Industrial Metal Structural Cold Rolled Mild Steel Plates Astm Carbon Steel Sheets For Machinery Processing Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled 0

Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled 1

Product name	Carbon steel sheet
Standard	GB/T700 standard:Q235A,Q235B,Q235C,Q235D,Q235E
	EN10025 standard:S235JR,S235J0,S235J2
	DIN 17100 standard:St33,St37-2,Ust37-2,RSt37-2,St37-3
	DIN 17102 standard:StE255,WstE255,TstE255,EstE255
	ASTM standard:A36/A36M A36
	A283/A283M A283 Grade A,A283 Grade B
	A283 Grade C,A283 Grade D
	A573/A573M A573 Grade 58,
	Grade 65,Grade 70
Material	Carbonsteel:Q195-Q420Series,SS540 Series
Material	S235JR-S355JR Series,ST Series,A36-A992 Series,Gr50 Series,etc
Surface	Mild steel plain finish,hot dip galvanized,color coated
Package	Export standard package:bundled wooden box or be required;
	The inner size of container is below:
	(1)20foot GP:5.8m(length)2.13m(width)2.18m(high) about 24-26 CBM
	(2)40foot GP:11.8m(length)2.13m(width)2.72m(high) about 68 CBM
	We will packing as the factory,and reach the stander of export.

Standard	Grade
ASTM A36	A36/A36-B
ASTM A283	A283-B/A283C
ASTM A516	A516Gr70
JIS G 3101	SS400-B
JIS G3136	SN400B
EN10025-2:2004	S235JR-S355K2+N

Grade	Rank	Chemical Composition( %)
Grade	Rank	C	Mn	Si	S	P
Q195		0.06~0.12	0.25~0.50	≤0.3	≤0.05	≤0.045
Q215	A	0.09~0.15	0.25~0.55	≤0.3	≤0.05	≤0.045
Q215	B	0.09~0.15	0.25~0.55	≤0.3	≤0.045	≤0.045
Q235	A	0.14~0.22	0.30~0.65	≤0.3	≤0.05	≤0.045
	B	0.12~0.20	0.30~0.70	≤0.3	≤0.045	≤0.045
	C	≤0.18	0.35~0.80	-	≤0.04	≤0.04
	D	≤0.17	0.35~0.80	-	≤0.035	≤0.035
Q255	A	0.18~0.28	0.40~0.70	≤0.3	≤0.05	≤0.045
Q255	B	0.18~0.28	0.40~0.70	≤0.3	≤0.045
Q275		0.28~0.38	0.50~0.80	≤0.35	≤0.05	≤0.045

Item	Hardox	GB Standard	BS Standard
Wear Resistance plate	B-HARD400A	NM360A	B-HARD360A
	B-HARD400B	NM400A	B1150GJ
	HARDOX500	NM450A
	HARDOX550	NM500A

GAUGE	steel	Galvanized steel	Stainless steel	aluminum	Electrical steel

(Ga.)
	in (mm)	in (mm)	in (mm)	in (mm)	in (mm)
3	0.2391 (6.07)	-	-	-	-
4	0.2242 (5.69)	-	-	-	-
6	0.1943 (4.94)	-	-	0.162 (4.1)	-
7	0.1793 (4.55)	-	0.1875 (4.76)	0.1443 (3.67)	-
8	0.1644 (4.18)	0.1681 (4.27)	0.1719 (4.37)	0.1285 (3.26)	-
9	0.1495 (3.80)	0.1532 (3.89)	0.1563 (3.97)	0.1144 (2.91)	-
10	0.1345 (3.42)	0.1382 (3.51)	0.1406 (3.57)	0.1019 (2.59)	-
11	0.1196 (3.04)	0.1233 (3.13)	0.1250 (3.18)	0.0907 (2.30)	-
12	0.1046 (2.66)	0.1084 (2.75)	0.1094 (2.78)	0.0808 (2.05)	-
13	0.0897 (2.28)	0.0934 (2.37)	0.094 (2.4)	0.072 (1.8)	-
14	0.0747 (1.90)	0.0785 (1.99)	0.0781 (1.98)	0.0641 (1.63)	-
15	0.0673 (1.71)	0.0710 (1.80)	0.07 (1.8)	0.057 (1.4)	-
16	0.0598 (1.52)	0.0635 (1.61)	0.0625 (1.59)	0.0508 (1.29)	-
17	0.0538 (1.37)	0.0575 (1.46)	0.056 (1.4)	0.045 (1.1)	-
18	0.0478 (1.21)	0.0516 (1.31)	0.0500 (1.27)	0.0403 (1.02)	-
19	0.0418 (1.06)	0.0456 (1.16)	0.044 (1.1)	0.036 (0.91)	-
20	0.0359 (0.91)	0.0396 (1.01)	0.0375 (0.95)	0.0320 (0.81)	-
21	0.0329 (0.84)	0.0366 (0.93)	0.034 (0.86)	0.028 (0.71)	-
22	0.0299 (0.76)	0.0336 (0.85)	0.031 (0.79)	0.025 (0.64)	0.0310 (0.787)
23	0.0269 (0.68)	0.0306 (0.78)	0.028 (0.71)	0.023 (0.58)	0.0280 (0.711)
24	0.0239 (0.61)	0.0276 (0.70)	0.025 (0.64)	0.02 (0.51)	0.0250 (0.64)
25	0.0209 (0.53)	0.0247 (0.63)	0.022 (0.56)	0.018 (0.46)	0.0197 (0.50)
26	0.0179 (0.45)	0.0217 (0.55)	0.019 (0.48)	0.017 (0.43)	0.0185 (0.47)
27	0.0164 (0.42)	0.0202 (0.51)	0.017 (0.43)	0.014 (0.36)	-
28	0.0149 (0.38)	0.0187 (0.47)	0.016 (0.41)	0.0126 (0.32)	-
29	0.0135 (0.34)	0.0172 (0.44)	0.014 (0.36)	0.0113 (0.29)	0.0140 (0.35)
30	0.0120 (0.30)	0.0157 (0.40)	0.013 (0.33)	0.0100 (0.25)	0.011 (0.27)
31	0.0105 (0.27)	0.0142 (0.36)	0.011 (0.28)	0.0089 (0.23)	0.0100 (0.25)
32	0.0097 (0.25)	-	-	-	-
33	0.0090 (0.23)	-	-	-	0.009 (0.23)
34	0.0082 (0.21)	-	-	-	-
35	0.0075 (0.19)	-	-	-	-
36	0.0067 (0.17)	-	-	-	0.007 (0.18)
37	0.0064 (0.16)	-	-	-	-
38	0.0060 (0.15)	-	-	-	0.005 (0.127)

Industrial Metal Mild Carbon Steel Structural Plate ASTM A36 Cold Rolled 2
